Description:
Vicker designed high flow, pressure and speed vane pump meet the needs of modern vehicle hydraulic circuits. long life for rugged applications. Internal inlet and outlet pressure chambers are diametrically opposed, as a result, pressure-induced radial loads are balanced. So bearings have to carry the external load only. Low vane tip/ring loading allows high pressure operation. High speeds are possible because the inlet flow paths are designed to give uniform oil acceleration - thus better filling - particularly at low inlet pressures. V10/V20 efficient design produces extra horsepower - providing low pump cost per horsepower.
| Model | Displacement code | Geometric displacement mL/r | Max. speed Rpm | Max. pressure Mpa |
| V10 | 1 | 3.3 | 4800 | 172 |
| 2 | 6.6 | 4500 | ||
| 3 | 9.8 | 4000 | ||
| 4 | 13.1 | 3400 | ||
| 5 | 16.4 | 3200 | ||
| 6 | 19.5 | 3000 | 152 | |
| 7 | 22.8 | 2800 | 138 | |
| V20 | 6 | 19.5 | 3400 | 172 |
| 7 | 22.8 | 3000 | ||
| 8 | 26.5 | 2800 | ||
| 9 | 29.7 | 2800 | ||
| 11 | 36.4 | 2500 | ||
| 12 | 39 | 2400 | 152 | |
| 13 | 42.4 | 2400 |
